Cloth Paper Bag Making Machine

This bag making machine is designed for the automatic production of paper shopping bags with twisted handles, equipped with 4-color inline printing machine, which is an ideal choice for bag making operations looking to minimize operating costs without sacrificing quality.
Availability:
Quantity:

Model

RKHF-330T

RKHF-450T

RKHF-450BT

RKHF-550T

Paper bag cutting length (C)

260-530mm(without handle)

260-530mm(without handle)

360-800mm(without handle)

360-800mm(without handle)

260-430mm(with handle)

260-430mm(with handle)

360-700mm(with handle)

360-700mm(with handle)

Paper bag width (W)

130-330mm(without handle)

180-450mm(without handle)

220-450mm(without handle)

220-550mm(without handle)

220-330mm(with handle)

250-450mm(with handle)


250-450mm(with handle

250-550mm(with handle)

Paper bag bottom width (H)

70-180mm

90-180mm

90-180mm

100-250mm

Paper roll width

430-1050mm

570-1290mm

670-1430mm

670-1630mm

Paper thickness

60-160g/m2(without handle)

60-160g/m2(without handle)

60-160g/m2(without handle)

80-160g/m2(with handle)

80-160g/m2(with handle)

80-160g/m2(with handle)

80-160g/m2(with handle)

60-160g/m2(without handle)

Max. speed

120-200pcs/min

120-200pcs/min

120-200pcs/min

120-200pcs/min

Flat handle width

12mm

12mm/15mm(choose one size)

12mm/15mm(choose one size)

12/15mm(choose one size)

Handle patch length

152mm

190mm

190mm

190mm

Handle patch width

45mm

50mm

50mm

50mm

Handle Height(with sheet)

140-150mm

140-150mm

140-150mm

140-150mm

Power

25KW

25KW

30KW

30KW

Dimension

L12000*W5400*H2600mm

L12000*W5600*H2600mm

L13500*W5700*H2600mm

L13500*W5700*H2600mm



What is cloth paper bag making machine?

Cloth paper bag making machine is a machine that produces paper bags. These machines vary in capacity and operation. They can produce up to 25000 bags per hour. Productivity depends on paper and machine. Paper bag machines can be expensive. The initial investment in a machine is usually higher than the operating costs. Still, the initial cost is worth it. These machines help create bags for a variety of products, including grocery bags and other merchandise.

The feeding process consists of supplying material to the cutting and sealing sections. The feeder ensures accurate feeding. The feeding process also involves the use of print mark sensors to ensure accurate supply of the printed web.

After feeding, the machine performs the forming process. The material passes through a series of heating and cooling elements that provide an effective seal. The temperature of these elements must be adjusted according to the quality of the material. Higher quality materials require longer sealing times and higher temperatures.


Why choose cloth paper bag making machine?

The cloth paper bag making machine can improve the appearance and mechanical properties of the bag. Additionally, the machine uses two servo motors to help control the amount of glue and provide a perfect cut. Its compact design makes it easy to handle.

The pointed bottom paper bags are made of coated porcelain clay paper with a smooth finish for custom bags. Paper can be found in different colors, making it versatile. Manufacturers offer pointed bottom paper bag making machines and they make fully automatic and user-friendly machines. Cloth paper bag making machine has several advantages that make it an excellent choice for your company.


What are the advantages of cloth paper bag making machine?

The cloth paper bag making machine is simple and dedicated in design. This machine has a special unsealed bag feeding system, which is fed into the bottom of the paper bag by vacuum adsorption.

The cloth paper bag making machine adopts water-soluble cold glue and environment-friendly glue to ensure that the glue on the bottom of the paper bag is firm. It has three automatic functions of feeding, pasting and automatic glue spraying. It can produce bags of various specifications with high precision and fast speed.


Previous:
Next:

FAQ

Wenzhou Rokin Machinery CO. Ltd is the manufacturer of full automatic paper bag machine, v bottom paper bag machine, square bottom paper bag machine and related auxiliary equipment, etc. We have many professional engineers who have more than twenty years experience in the packaging equipment manufacturing industry.

  • Q Are you manufacturer or trading company?

    A We are the manufacturer and have over 200 workers.
  • Q Where is your factory located? May I have a visit?

    A Warmly welcome! Our factory is located in Wenzhou city.
  • Q How is the quality of your machine?

    A We are in machine manufacturer over 20 years and regard quality as the life of the enterprise.We choose the world famous manufacturers as our suppliers. And besides, we have our own quality inspector.Machine parts are checked one by one according to the drawings! Good quality and good after-sales help us obtain good reputation in the international market! We have a technical team of seven person and at the same time cooperate with other Research Institutes.We are committed to providing customers with the best packaging machine.
  • Q What information should I let you know if I want to get a quotation?

    A First, Paper raw material: Reel paper or Sheet Paper.
    Second, sizes of the paper bag, thickness of paper.
    Send sample bag picture if available.
    Then we will recommend the right machine to you!
