Auto Paper Bag Making Machine

The auto paper bag making machine uses the creasing sheet as the raw material, and goes through the processes of Feida automatic paper suction, automatic alignment, gluing and pasting, automatic folding of the organ position, pressing and other processes, and finally outputs the formed paper tube. Water-soluble cold glue (optional glue spray system) is used in the gluing and pasting process. The auto paper bag making machine is the ideal equipment for making high-end handbags. Speed: 100 m/min.
Availability:
Quantity:

Model

RKHF-330F

RKHF-450F

RKHF-450BF

RKHF-550F

Paper bag cutting length (C)

260-530mm(without handle)

260-530mm(without handle)

360-800mm(without handle)

360-800mm(without handle)

260-430mm(with handle)

260-430mm(with handle)

360-700mm(with handle)

360-700mm(with handle)

Paper bag width (W)

130-330mm(without handle)

180-450mm(without handle)

220-450mm(without handle)

220-550mm(without handle)

220-330mm(with handle)

250-450mm(with handle)

250-450mm(with handle)

250-550mm(with handle)

Paper bag bottom width (H)

70-180mm

90-180mm

100-250mm

100-250mm

Paper roll width

430-1050mm

570-1290mm

670-1430mm

670-1630mm

Paper thickness

60-160g/m2(without handle)

60-160g/m2(without handle)

60-160g/m2(without handle)

60-160g/m2(without handle)

80-160g/m2(with handle)

80-160g/m2(with handle)

90-160g/m2(with handle)

90-160g/m2(with handle)

Max. speed

120-200pcs/min

120-200pcs/min

120-200pcs/min

120-200pcs/min

Flat handle width

12mm

12mm/15mm(choose one size)

12mm/15mm(choose one size)

12/15mm(choose one size)

Handle patch length

152mm

190mm

190mm

190mm

Handle patch width

45mm

50mm

50mm

50mm

Handle Height(with sheet)

140mm

140mm

140mm

140mm

Power

25KW

25KW

30KW

30KW

Dimension

L12000*W5400*H2600mm

L12000*W5600*H2600mm

L13500*W5700*H2600mm

L13500*W5700*H2600mm


What are the scope and materials of auto paper bag making machine?

Applicable paper quality: kraft paper, coated paper, white paper, white cardboard (including laminated paper)

The auto paper bag making machine is to manually put the unsealed paper tube into the bottom card, and then go through the processes of automatic conveying, automatic glue spraying, automatic bottom sticking, automatic compaction, etc., and output it as a back-sealing paper bag. The machine is equipped with four spray guns, and customers can adjust the thickness of the glue and the position of the glue according to the requirements of the paper bag. Speed: 60-80 m/min


What is the actual use value of auto paper bag making machine?

In production, there are countless places where various bags need to be used, and almost all of these bags need to be perfectly seamed. In these industries, it is common to use seam technology in chemicals, food, building materials And other industries that require a lot of packaging, and these industries include all aspects of life, food, clothing, housing and transportation, almost every corner needs the convenient, fast, strong and beautiful sewing technology of auto paper bag making machine.


What is the use principle of auto paper bag making machine

This type of heat sealing machine is simple in structure and basic principle, and has a faster sealing speed, so it is generally used for heat sealing of high pressure polyethylene film and polyethylene composite film. However, it is not suitable for heat sealing of films that are easily folded or dissolved when exposed to heat. Single-pulse heat sealing. For example, the film of the nickel-chromium alloy strip is pressed on the high-temperature plastic, and the nickel-chromium alloy strip is heated according to the large current in an instant, and the sealing is carried out by this heat.
