Model | RKP2-1000 | RKP2-1200 | RKP2-1400 | RKP2-1500 | RKP2-1700 |
Colors | 2 colors | 2 colors | 2 colors | 2 colors | 2 colors |
Max. Printing material width | 1000mm | 1200mm | 1400mm | 1500mm | 1700mm |
Max. Printing width | 960mm | 1160mm | 1360mm | 1460mm | 1680mm |
Printing length range | 230-1000mm | 230-1000mm | 230-1000mm | 230-1000mm | 230-1000m |
Max. Printing speed | 5-100m/min | 5-100m/min | 5-100m/min | 5-100m/min | 5-100m/min |
Register precision | ≤±0.15mm | ≤±0.15mm | ≤±0.15mm | ≤±0.15mm | ≤±0.15m |
Thickness of plate | 2.28mm+0.38mm(can be customized) | 2.28mm+0.38mm(can be customized) | 2.28mm+0.38mm(can be customized) | 2.28mm+0.38mm(can be customized) | 2.28mm+0.38mm(can be customized) |
Max. Rewinding diameter | 1300mm | 1300mm | 1300mm | 1300mm | 1300mm |
Max. Unwinding diameter | 1300mm | 1300mm | 1300mm | 1300mm | 1300mm |
Power | 16KW | 19KW | 16KW | 21KW | 23KW |
Dimension | L6600*W2100*H2500mm | L6600*W2300*H2500mm | L6600*W2500*H2500mm | L6600*W2550*H2500mm | L6600*W2750*H2500mm |
What is the definition of Automatic Paper Bag Machine?
When it comes to Automatic Paper Bag Machine, everyone must be familiar with it. It is a packaging equipment and belongs to the category of equipment accessories. It is mainly composed of four parts: feeding, gluing, forming and cutting. Due to the needs of the modern market, processes such as dispensing and puncturing have been added. The feeding part can be designed with 1-4 layers of feeding racks according to the requirements of the finished product, so it is also called multi-layer kraft paper bag machine.
What is the use value of bread handle type paper bag making machine?
bread handle type paper bag making machineis a new generation of multi-layer kraft paper bag making machine designed to solve environmental pollution and comply with environmental protection. It can be used for making bags from 70-140 grams of kraft paper rolls. The operation is simple, convenient and fast, and it can produce single-layer packaging bags or multi-layer packaging bags of different bag types such as gusset bags, non-gusset bags, and other bag types.
What are the structure and usage characteristics of bread handle type paper bag making machine?
The unit of bread handle type paper bag making machine is equipped with advanced electrical systems and mechanical devices throughout the entire process from substrate feeding, tube forming, edge bonding, bag cutting, and bag conveying, and adopts a servo system combined with a human-machine interface. The base material is continuously completed in one process flow from feeding to bag making, with a high degree of automation. With advanced bag-making technology, reasonable equipment structure, and beautiful and reliable tube bags, it is an ideal equipment for bag-making companies all over the world to produce various types of packaging bags.
Model | RKP2-1000 | RKP2-1200 | RKP2-1400 | RKP2-1500 | RKP2-1700 |
Colors | 2 colors | 2 colors | 2 colors | 2 colors | 2 colors |
Max. Printing material width | 1000mm | 1200mm | 1400mm | 1500mm | 1700mm |
Max. Printing width | 960mm | 1160mm | 1360mm | 1460mm | 1680mm |
Printing length range | 230-1000mm | 230-1000mm | 230-1000mm | 230-1000mm | 230-1000m |
Max. Printing speed | 5-100m/min | 5-100m/min | 5-100m/min | 5-100m/min | 5-100m/min |
Register precision | ≤±0.15mm | ≤±0.15mm | ≤±0.15mm | ≤±0.15mm | ≤±0.15m |
Thickness of plate | 2.28mm+0.38mm(can be customized) | 2.28mm+0.38mm(can be customized) | 2.28mm+0.38mm(can be customized) | 2.28mm+0.38mm(can be customized) | 2.28mm+0.38mm(can be customized) |
Max. Rewinding diameter | 1300mm | 1300mm | 1300mm | 1300mm | 1300mm |
Max. Unwinding diameter | 1300mm | 1300mm | 1300mm | 1300mm | 1300mm |
Power | 16KW | 19KW | 16KW | 21KW | 23KW |
Dimension | L6600*W2100*H2500mm | L6600*W2300*H2500mm | L6600*W2500*H2500mm | L6600*W2550*H2500mm | L6600*W2750*H2500mm |
What is the definition of Automatic Paper Bag Machine?
When it comes to Automatic Paper Bag Machine, everyone must be familiar with it. It is a packaging equipment and belongs to the category of equipment accessories. It is mainly composed of four parts: feeding, gluing, forming and cutting. Due to the needs of the modern market, processes such as dispensing and puncturing have been added. The feeding part can be designed with 1-4 layers of feeding racks according to the requirements of the finished product, so it is also called multi-layer kraft paper bag machine.
What is the use value of bread handle type paper bag making machine?
bread handle type paper bag making machineis a new generation of multi-layer kraft paper bag making machine designed to solve environmental pollution and comply with environmental protection. It can be used for making bags from 70-140 grams of kraft paper rolls. The operation is simple, convenient and fast, and it can produce single-layer packaging bags or multi-layer packaging bags of different bag types such as gusset bags, non-gusset bags, and other bag types.
What are the structure and usage characteristics of bread handle type paper bag making machine?
The unit of bread handle type paper bag making machine is equipped with advanced electrical systems and mechanical devices throughout the entire process from substrate feeding, tube forming, edge bonding, bag cutting, and bag conveying, and adopts a servo system combined with a human-machine interface. The base material is continuously completed in one process flow from feeding to bag making, with a high degree of automation. With advanced bag-making technology, reasonable equipment structure, and beautiful and reliable tube bags, it is an ideal equipment for bag-making companies all over the world to produce various types of packaging bags.
