Characteristic of Handle Bags
Comfortable and portable: Handle bags have sturdy handles that make carrying heavy items comfortable and easy.
Handle bags come with different closure options such as drawstring, zipper, or snap button.
Eco-friendly: Some handle bags are eco-friendly, made from biodegradable materials that are environmentally responsible.
They are available in different sizes, materials, and colors to suit various needs.
Handle bags come with different closure options such as drawstring, zipper, or snap button.
Catalog of Handle Bag
What Can Rokin Machines Customize?
Paper bag cutting length
Paper bag width
Paper bag bottom width
The handle has round or flat ropes
The color of the handle is determined by the color of the raw material purchased by the customer.
 The bag can be made with printing (customers can purchase printed and brushed paper rolls or purchase a printing machine to print and reproduce the bag themselves)
Parameters of Handle Bag
Model RKHF-330T RKHF-450T RKHF-450BT RKHF-550T
Cutting length(without handle) 260-530mm 260-530mm 360-800mm 360-800mm
Cutting length(with handle) 260-430mm 260-430mm 360-700mm 360-700mm
Paper bag height(without handle) 180-475mm 180-475mm 250-730mm 250-730mm
Paper bag height(with handle) 185-375mm 185-375mm 260-630mm 260-630mm
Paper bag width(without handle) 130-330mm 150-450mm 220-450mm 220-550mm
Paper bag width(with handle) 220-330mm 250-450mm 250-450mm 250-550mm
Paper bag bottom width 70-180mm 70-180mm 100-250mm 100-250mm
Paper thickness(without handle) 60-160g/m² 60-160g/m² 60-160g/m² 60-160g/m²
Twisted handle diameter 3-4mm 3-4mm 3-4mm 3-4mm
Handle patch length 152mm 190mm 190mm 190mm
Handle patch width 45mm 50mm 50mm 50mm
Handle patch thickness 100-120g/m² 100-120g/m² 100-120g/m² 100-120g/m²
Twisted handle height 140-150mm 140-150mm 140-150mm 140-150mm
Paper roller width 430-1050mm 570-1290mm 670-1430mm 670-1630mm
Max. diameter of paper roller 1200mm 1200mm 1200mm 1200mm
Paper roller inner diameter 76mm 76mm 76mm 76mm
Power 25kw 25kw 30kw 30kw
Machine speed 60-150pcs/min 60-150pcs/min 30-120pcs/min 30-100pcs/min
Air supply >0.12m³/min 0.6MPa >0.12m³/min 0.6MPa >0.12m³/min 0.6MPa >0.12m³/min 0.6MPa
Machine weight 18tons 19.5tons 19.5tons 23tons
Machine dimension(L×W×H) 12000x5400x2600mm 12000x5600x2600mm 13500×5700×2600mm 13500×5700×2600mm

Model RKHF-330F RKHF-450F RKHF-450BF RKHF-550F
Cutting length(without handle) 260-530mm 260-530mm 360-800mm 360-800mm
Cutting length(with handle) 260-430mm 260-430mm 360-700mm 360-700mm
Paper bag height(without handle) 180-475mm 180-475mm 250-730mm 250-730mm
Paper bag height(with handle) 185-375mm 185-375mm 260-630mm 260-630mm
Paper bag width(without handle) 130-330mm 180-450mm 220-450mm 220-550mm
Paper bag width(with handle) 220-330mm 250-450mm 250-450mm 250-550mm
Paper bag bottom width 70-180mm 70-180mm 100-250mm 100-250mm
Paper thickness(without handle) 60-160g/m² 60-160g/m² 60-160g/m² 60-160g/m²
Paper thickness(with handle) 80-160g/m² 80-160g/m² 90-160g/m² 90-160g/m²
Twisted handle diameter 3-4mm 3-4mm 3-4mm 3-4mm
Flat handle width 12mm 12m/15mm 12mm/15mm 12mm/15mm
Flat handle thickness 100-120g/m² 100-120g/m² 100-120g/m² 100-120g/m²
Handle patch length 152mm 190mm 190mm 190mm
Handle patch width 45mm 50mm 50mm 50mm
Handle patch thickness 100-120g/m² 100-120g/m² 100-120g/m² 100-120g/m²
Flat handle height 140mm 140mm 140mm 140mm
Paper roller width 430-1050mm 570-1290mm 670-1430mm 670-1630mm
Max. diameter of paper roller 1200mm 1200mm 1200mm 1200mm
Paper roller inner diameter 76mm 76mm 76mm 76mm
Power 25kw 25kw 30kw 30kw
Machine speed 60-150pcs/min 60-150pcs/min 30-120pcs/min 30-100pcs/min
Air supply >0.12m³/min 0.6MPa >0.12m³/min 0.6MPa >0.12m³/min 0.6MPa >0.12m³/min 0.6MPa
Machine weight 18tons 19.5tons 19.5tons 23tons
Machine dimension(L×W×H) 12000x5400x2600mm 12000x5600x2600mm 13500×5700×2600mm 13500×5700×2600mm
